Measure gauge for cover plate

Product information:



This device conforms to the standard of IEC60884-1 figure 32. It is used to check the contour line of the cover or the cover plate,



Technical parameters:



Material: stainless steel

Thickness:2mm



Picture view:

Standard drawing:

IEC 60884-1:2022 Figure 34 - Arrangement for test on covers or cover-plates standard drawing
IEC 60884-1:2022 Figure 34 – Arrangement for test on covers or cover-plates
IEC 60884-1:2022 Figure 35 - Gauge for verification of the outline of covers or cover-plates standard drawing
IEC 60884-1:2022 Figure 35 – Gauge for verification of the outline of covers or cover-plates
