Test Sphere Probe A with 50N Force IEC61032 Figure 1 IEC60529 IP1X SC-F1A-F
Product information:
Test sphere probe SC-F1A-F conforms to IEC61032 figure 1 and IEC60529 IP1X. It is the test sphere probe A with force: a 50N force is applied by the built-in dynamometer connection for verifying the protection of the back of hand of persons against access to hazardous parts.
It can be used for enclosure protection test when open threaded hole of M6 at the end of the handle (connected with pull and push dynamometer).
Technical parameters:
| Parameters / Model | SC-F1A-F | |
|---|---|---|
| Name | Name | Test probe A with force |
| 1 | 1 | SΦ50 +0.05/0 |
| 2 | 2 | Φ45±0.2 |
| 3 | 3 | Φ10 |
| 4 | 4 | 4 |
| 5 | 5 | 100 |
| 6 | 6 | With force of 50N |
| 7 | 7 | IEC60529 |
Standard drawing:
Product pictures:
